Ribbon Flat Optical Cable (RBC)

RBC optical fiber ribbon flat optical cable uses optical fiber ribbon as optical transmission medium, covers a layer of aramid as force strengthening unit, and extruded a layer of polyvinyl chloride (PVC) or low smoke halogen-free material (LSZH, low smoke, halogen-free, flame retardant) sheath.

Product application

• Indoor wiring
• Interconnection of instruments and communication equipment
• Strip connection jumper

Product characteristics

• Uses optical fiber tape, integration
• Aramid reinforced elements make optical cables have excellent tensile properties.
• External protection materials have the advantages of corrosion resistance, waterproof, UV protection, flame retardant, environmental protection, etc.

Cable parameters

Cable OD. （mm）	Weight （kg/km）		Tensile daily （kN）	Max. tensile daily （kN）	Broken strength （kN）	working temperature （℃）	Thermal expansion coefficient （10-6/K）	Span （m）
Cable OD. （mm）	PE Jacket	AT Jacket	Tensile daily （kN）	Max. tensile daily （kN）	Broken strength （kN）	working temperature （℃）	Thermal expansion coefficient （10-6/K）	Span （m）
9.0	75	85	1.20	3	7	-40~+60	1.2	50
9.8	80	90	1.50	5	10	-40~+60	1.3	100
10.0	85	95	2.00	6	15	-40~+60	1.3	150
10.8	95	100	2.20	8	18	-40~+60	1.3	200
